Ripper

Ripper

Ripper

Ripper
Designed to penetrate and loosen high-resistance surfaces, this ripper excels in hard soil, frozen ground, weathered rock, and soft rock. By effectively breaking up the terrain, it significantly reduces resistance for subsequent bucket work, maximizing the overall excavation efficiency of your machine.
Selection of Machine2 - 45 ton
Height
640 - 2,000 mm
Operating Weight
60 - 1,900 kg

Designed to penetrate and loosen high-resistance surfaces, this ripper excels in hard soil, frozen ground, weathered rock, and soft rock. By effectively breaking up the terrain, it significantly reduces resistance for subsequent bucket work, maximizing the overall excavation efficiency of your machine.

Selection of Machine
2 - 45 ton
Height
640 - 2,000 mm
Operating Weight
60 - 1,900 kg
mobile background

Find the Best Products for Your Job Site

Specifications

SpecificationJFR02JFR04JFR06JFR08JFR10JFR12JFR14
Opening Widthmm110-160150-230220-300300-360360-410410-480480-550
Center Distancemm170-245240-300300-420400-510480-560530-600580-680
Shaft Diametermm35-4040-5560-7080-9090-100100-110110-120
Heightmm64093012401360150016602000
Main Plate Thicknessmm505060808090100
Bucket Tooth Model-DH55DH150DH220D85D854T55024T5502
Weight (excl. pins)kg601302704506409501900
Suitable Excavatorton2-45-89-1617-2324-3031-3536-45

Specifications and features are subject to change without notification to better improvenet in quality.
